The advancement of technology has revolutionized multiple industries, and drones are no exception. In this regard, DJI, the world leader in civilian drones and creative camera technology, presents its latest creation: the DJI Matrice 350 RTK (M350 RTK). This powerful drone is positioned as the ultimate tool for the commercial drone industry, offering new capabilities and enhanced features that put it at the forefront of the market.
More power and versatility for demanding missions
The M350 RTK has been designed to suit a wide range of operations, from public safety to mapping and forestry. With a maximum flight time of 55 minutes and a payload capacity of 2.7 kg, operators have the flexibility to choose the payloads that best suit their specific missions. This versatility is further enhanced by the DJI O3 Enterprise Transmission System, which provides real-time 1080p HD video transmission via triple channel with a maximum transmission distance of 20 km. Thanks to a four-antenna transceiver system, the drone can intelligently select the best antennas to transmit signals and receive signals simultaneously, improving stability and resistance to interference.
Specifications
Here is a list of the key specifications of the DJI Matrice 350 RTK:
- Maximum flight time: 55 minutes.
- Payload capacity: 2.7 kg.
- Video transmission: DJI O3 Enterprise with live HD signals in 1080p by triple channel.
- Maximum transmission distance: 20 km.
- Four antenna transceiver system for optimal signal transmission.
- IP protection index: IP55 (dust and water resistant).
- Drone arms insurance detection system.
- Binocular vision system in six directions.
- Infrared detection system.
- Option to add CMS radar for detection of subtle obstacles (range up to 30 m).
- Battery: TB65 with higher battery cycle count (up to 400 charge cycles).
- Dual battery system with hot swap capability.
- BS65 smart battery station for charging, storage and transport of batteries.
- Compatible with Zenmuse H20 series payloads, including zoom cameras, thermal camera, and laser rangefinder.
- Compatible with the Zenmuse P1 payload, designed for photogrammetry missions.
- Compatible with the Zenmuse L1 payload, which integrates LiDAR and mapping camera.
- Support for custom payloads via the DJI Payload SDK.
- Smart features like Trajectory, Mapping, Linear Flight, AI Targeting and more.
- Integration with the DJI SDK and API ecosystem for further customization and expansion.
These are just some of the standout specs of the DJI Matrice 350 RTK.
Enhanced security and reliability
In terms of flight safety, the M350 RTK has undergone significant improvements. Its IP protection index has increased from IP45 to IP55, which means that it is resistant to dust and water. In addition, it has a detection system for the safety of the drone’s arms, avoiding the risk that the covers of the arms do not close correctly during the flight. The drone is also equipped with a six-way binocular vision system and an infrared sensing system, which offer comprehensive protection by detecting and avoiding obstacles in all directions.
For added safety, operators can separately purchase a CMS radar that provides subtle obstacle detection within a 30m range.
Increased efficiency and cost reduction
Efficiency is key in any operation, and the M350 RTK offers innovative solutions to improve it. The drone’s TB65 battery has a higher battery cycle count, allowing up to 400 charge cycles.
Its dual battery system supports hot swapping, which means multiple flights can be performed without powering off the drone. The BS65 Smart Battery Station provides a comprehensive solution for charging, storing and transporting batteries, with customizable charging modes to suit the operator’s needs.
payloads
The DJI Matrice 350 RTK offers a wide range of powerful payloads that can be used to suit various applications in the commercial drone industry. These payloads provide specialized capabilities that allow operators to obtain detailed information and perform specific tasks efficiently. Next, we’ll explore some of the featured payloads supported by the M350 RTK:
Zenmuse H20 Series: Versatility in Sensing and Imaging
The Zenmuse H20 series is a versatile payload that combines four sensors in a single unit. This payload includes a zoom camera, a wide-angle camera, a thermal camera, and a laser rangefinder. By working in conjunction with advanced intelligent algorithms, the Zenmuse H20 series delivers exceptional detection and imaging performance.
The zoom camera enables sharp, detailed images from various distances, ideal for applications such as public safety, infrastructure inspection, and mapping. The wide-angle camera provides a wide and detailed panoramic view for mapping and monitoring applications. The thermal camera allows the detection and visualization of temperature differences, which is especially useful in search and rescue applications, inspection of power lines and fire detection. Finally, the laser rangefinder allows you to measure precise distances and calculate dimensions, which is essential in surveying and construction applications.
Zenmuse P1: High efficiency and precision photogrammetry
The Zenmuse P1 payload is specifically designed for photogrammetry missions. This payload integrates a full-frame sensor with interchangeable fixed-focus lenses, all mounted on a 3-axis stabilizer. The Zenmuse P1 allows you to capture high-quality, high-resolution aerial images, which is essential for generating accurate and detailed 3D models of terrain, buildings, and other features.
The Zenmuse P1 offers exceptional efficiency and accuracy when performing photogrammetry tasks, making it a valuable tool for applications such as terrain mapping, urban planning, infrastructure inspection, and precision agriculture. With this payload, operators can obtain detailed and accurate data, allowing them to make informed decisions and maximize efficiency on their projects.
Zenmuse L1: Real-time 3D data capture
The Zenmuse L1 payload is a complete solution that combines a Livox LiDAR module, a high-precision IMU, and a mapping camera. Using the M350 RTK flight platform, the Zenmuse L1 allows you to capture real-time 3D data around the clock. This payload is especially useful for capturing details of complex structures and generating highly accurate 3D models.
LiDAR is a laser scanning technology that allows you to measure distances and obtain detailed information of the environment in 3D. With the Zenmuse L1, operators can perform topographic surveying, infrastructure inspection, building modeling, and more, efficiently obtaining accurate and detailed data.
Third-party and custom payloads
In addition to the payloads mentioned above, the M350 RTK supports third-party payloads via the DJI Payload SDK. This means that operators have the flexibility to integrate custom payloads such as gas detectors, speakers and multispectral sensors to further expand the capabilities and applications of the drone.
The ability to use third-party and custom payloads gives operators the freedom to tailor the M350 RTK to their specific needs and get the most out of the platform. This allows for greater versatility and opens the way for new applications and discoveries in the commercial drone industry.
A Scalable Ecosystem and Final Thoughts
The M350 RTK is not only a powerful drone platform in its own right, but also part of an extensible ecosystem. Through the DJI SDK and API ecosystem, operators can integrate third-party payloads and develop highly customizable mobile apps to meet their specific needs.
As you can see, the DJI Matrice 350 RTK is a sample of the continuous technological advancement in the commercial drone industry. Its enhanced features such as increased power, safety, efficiency, and payload expandability make it a valuable and versatile tool for a variety of applications.
You have more information about it at enterprise.dji.com/matrice-350-rtk
